Home IMC/RMC Conduit System Rigid 90° Pull Elbow – Rigid-to-Box – Zinc Die Cast

Threaded Zinc Die-Cast Pull Elbow for RMC/IMC-to-Enclosure Turns

Rigid 90° Pull Elbow – Rigid-to-Box – Zinc Die Cast

Velkor RIGID-to-box pull elbows turn threaded RMC or IMC 90 degrees at an enclosure entry while keeping the conductor path accessible. The zinc die-cast elbow body is designed for close-clearance layouts where a full-radius conduit bend would require more space near the box.

A CLOSE 90° TURN AT THE ENCLOSURE This pull elbow is for the point where a threaded RMC or IMC run must turn and terminate at a box. Its compact geometry moves the direction change into the fitting, and the removable access cover supports conductor pulling and later access through a turn that would otherwise […]

MATERIAL

Zinc Die Cast

FINISH

Natural Zinc Alloy Finish

TRADE SIZES

1/2–2 in

Catalog No.

VK-361–VK-366

ADD TO INQUIRY

REQUEST A QUOTE

A CLOSE 90° TURN AT THE ENCLOSURE

This pull elbow is for the point where a threaded RMC or IMC run must turn and terminate at a box. Its compact geometry moves the direction change into the fitting, and the removable access cover supports conductor pulling and later access through a turn that would otherwise be difficult to reach.

Select this RIGID-to-box configuration when one side terminates at an enclosure. The RIGID-to-RIGID version is the correct sibling product when both ends continue as threaded conduit.

Threaded conduit end connects the pull elbow to compatible RMC or IMC.
Box-entry end completes the 90-degree transition at the enclosure.
Removable access cover gives installers an opening along the conductor path.
Compact elbow body reduces the space needed compared with a large conduit sweep.

TYPICAL APPLICATIONS

Tight enclosure entries

Load centers

Threaded raceways

Industrial routing

Specifications

RIGID-to-Box Pull Elbow

VK-361–VK-366

RIGID-to-Box 90° Pull Elbow

Standard

UL514B

Material

Zinc Die Cast

Finish

Natural Zinc Alloy Finish

Click a row to add it to your inquiry.

Catalog No.	Trade Size
VK-361	1/2 in
VK-362	3/4 in
VK-363	1 in
VK-364	1-1/4 in
VK-365	1-1/2 in
VK-366	2 in

CUT SHEET (PDF)

Confirm the conduit thread and enclosure-entry configuration for the selected size; nominal trade size does not verify thread compatibility.

Position the pull-access cover where it can be opened after installation and verify cover, gasket, screw and locknut supply before ordering.
