Home Flexible Conduit System Flexible Metal Conduit – Greenfield

Flexible routing for dry-location electrical installations

Flexible Metal Conduit – Greenfield

Velkor Greenfield Flexible Metal Conduit provides flexible and reliable cable routing around equipment, machinery, and tight installation spaces. Its galvanized steel construction forms a continuous flexible raceway, making it suitable for applications where rigid conduit is difficult to route or install. Greenfield flexible conduit is also commonly referred to as American Standard Steel Flexible Conduit. If you are looking for a square-locked construction with greater flexibility, please visit our Square-Locked Flexible Conduit (Ultra Flex) page.

FLEXIBILITY WHERE RIGID ROUTING STOPS Greenfield flexible metal conduit gives installers a practical way to route conductors around equipment, structural obstacles, and other areas where a rigid conduit path would require multiple bends. Its helically formed galvanized-steel construction allows the raceway to change direction while retaining a continuous metallic profile. This construction is particularly useful […]

MATERIAL

Galvanized steel

FINISH

Galvanized

LENGTH

15/30 Meters

TRADE SIZES

1/2"–4"

Catalog No.

VK4101–VK4110

O.D

20.90–115.80 mm

ADD TO INQUIRY

REQUEST A QUOTE

Need technical details? Download Spec Sheet (PDF, 1 MB)

FLEXIBILITY WHERE RIGID ROUTING STOPS

Greenfield flexible metal conduit gives installers a practical way to route conductors around equipment, structural obstacles, and other areas where a rigid conduit path would require multiple bends. Its helically formed galvanized-steel construction allows the raceway to change direction while retaining a continuous metallic profile.

This construction is particularly useful for short, adjustable runs and equipment connections. Buyers can select the required trade size using the confirmed minimum and maximum inside- and outside-diameter ranges shown in the specification table.

If heavy-duty steel flexible conduit is not a requirement for you, you can consider our square lock steel flexible conduit as better cost-effective option.

Flexible Metal Conduit – Square Lock

Flexible routing: Accommodates changes in direction without a series of rigid elbows.
Metallic construction: Provides a continuous galvanized-steel conduit profile.
Broad size range: Covers multiple trade sizes for different cable-routing requirements.
Dimensional selection: Minimum and maximum diameter data support fitting compatibility checks.

TYPICAL APPLICATIONS

Commercial Buildings

Industrial Facilities

Equipment Connections

Machinery Wiring

Short Flexible Conduit Runs

Flexible Metal Conduit Specifications

Greenfield

VK4101–VK4110

Greenfield Flexible Metal Conduit

Standard

UL1

Material

Galvanized steel

Finish

Galvanized

Click a row to add it to your inquiry.

Trade Size	Catalog No.	I.D. Min (mm)	I.D. Max (mm)	O.D. Min (mm)	O.D. Max (mm)
1/2"	VK-4101	15.90	16.30	20.90	23.30
3/4"	VK-4102	20.70	21.20	26.60	28.00
1"	VK-4103	25.40	26.40	33.00	35.00
1 1/4"	VK-4104	31.80	33.00	39.40	41.40
1 1/2"	VK-4105	38.20	40.00	48.70	49.40
2"	VK-4106	50.90	52.80	59.70	62.20
2 1/2"	VK-4107	63.60	64.40	72.70	77.70
3"	VK-4108	76.30	76.90	90.40	98.20
4"	VK-4110	101.70	102.80	110.80	115.80

Click any row to add that size to your inquiry.

CUT SHEET (PDF)

Dimensions are listed as minimum and maximum inside and outside diameters for each trade size.

Select conduit and fittings using the matching trade size and dimensional requirements.
