20–50 mm Flexible Steel Conduit with a UV-Resistant, Halogen-Free Jacket

UV-Resistant Flexible Metal Conduit

Velkor UV Series combines a flexible steel core with a UV-resistant, halogen-free thermoplastic jacket for cable protection along routes exposed to sunlight. Available in sizes from 20 to 50 mm, it provides a flexible connection between fixed conduit and equipment.

STEEL CORE WITH A UV-RESISTANT, HALOGEN-FREE JACKET The flexible steel core provides mechanical protection for wiring and accommodates changes in routing direction. The outer jacket combines UV resistance with a halogen-free thermoplastic formulation. Jacket thickness is 0.5 mm on 20–32 mm sizes and 0.7 mm on 40–50 mm sizes. UV-resistant jacket for cable routes exposed […]

MATERIAL

Steel core with a UV-resistant, halogen-free thermoplastic jacket

FINISH

Thermoplastic jacket

LENGTH

15–100 m coil options

TRADE SIZES

20–50 mm

Catalog No.

IEC-20UV–IEC-50UV

ADD TO INQUIRY

REQUEST A QUOTE

STEEL CORE WITH A UV-RESISTANT, HALOGEN-FREE JACKET

The flexible steel core provides mechanical protection for wiring and accommodates changes in routing direction. The outer jacket combines UV resistance with a halogen-free thermoplastic formulation. Jacket thickness is 0.5 mm on 20–32 mm sizes and 0.7 mm on 40–50 mm sizes.

TYPICAL APPLICATIONS

Sunlight-exposed cable routes

connections between fixed conduit and equipment

installations requiring a halogen-free conduit jacket.

Specifications

UV-Resistant

IEC-20UV–IEC-50UV

UV-Resistant Flexible Metal Conduit

Standard

IEC 61386

Material

Steel core with a UV-resistant, halogen-free thermoplastic jacket

Length

15–100 m coil options

Click a row to add it to your inquiry.

Catalog No.	Nominal Size	Diameter 1 Min./Max. (mm)	Diameter 2 Min./Max. (mm)	Steel Thickness (mm)	Cover Thickness (mm)	Minimum Bend Radius (mm)	Coil Length (m)
IEC-20UV	20 mm	15.2 / 16.2	19.0 / 20.0	0.2	0.5	40	25, 50, 100
IEC-25UV	25 mm	20.0 / 21.0	24.0 / 25.0	0.2	0.5	45	25, 50, 100
IEC-32UV	32 mm	26.0 / 27.0	30.5 / 31.5	0.2	0.5	55	15, 30, 50
IEC-40UV	40 mm	31.5 / 32.5	37.0 / 38.0	0.3	0.7	70	15, 30, 50
IEC-50UV	50 mm	40.5 / 41.5	46.0 / 47.5	0.3	0.7	280	15, 30

CUT SHEET (PDF)

Coil lengths are 25, 50 or 100 m for 20–25 mm sizes; 15, 30 or 50 m for 32–40 mm sizes; and 15 or 30 m for the 50 mm size.

The outer jacket is 0.5 mm thick on 20–32 mm sizes and 0.7 mm on 40–50 mm sizes.
