VELKOR FLEXIBLE CONDUIT SYSTEM

Non-Metallic Liquid-Tight Flexible Conduit

Velkor non-metallic flexible conduit provides a flexible raceway for equipment and enclosure connections.

A NON-METALLIC FLEXIBLE RACEWAY This range uses a non-metallic conduit construction for flexible equipment connections. It is a separate choice from jacketed flexible metal conduit: select the termination for the actual non-metallic conduit construction, rather than assuming a metallic-conduit connector will fit. The main distinction from PVC-coated flexible metal conduit is the conduit construction: a […]

MATERIAL

Non-metallic

TRADE SIZES

1/2"–2"

Catalog No.

VK-HF/CT38 ~ VK-HF/CT2

ADD TO INQUIRY

REQUEST A QUOTE

A NON-METALLIC FLEXIBLE RACEWAY

This range uses a non-metallic conduit construction for flexible equipment connections. It is a separate choice from jacketed flexible metal conduit: select the termination for the actual non-metallic conduit construction, rather than assuming a metallic-conduit connector will fit.

The main distinction from PVC-coated flexible metal conduit is the conduit construction: a coated metallic conduit retains a metal core, while this range is non-metallic. Greenfield conduit is also a metallic option, but without an outer jacket. Select the conduit family before the termination, because a connector intended for metal conduit is not automatically suitable for a non-metallic conduit of the same nominal size.

Flexible Metal Conduit – Greenfield

TYPICAL APPLICATIONS

Equipment connections

Enclosure approaches

Flexible links

Specifications

Non-Metallic Liquid-Tight Flexible Conduit

Non-Metallic Liquid-Tight Flexible Conduit

Material

Non-metallic

Click a row to add it to your inquiry.

VELKOR CAT#	TRADE SIZE	INSIDE DIAMETER (MM)		OUTSIDE DIAMETER (MM)
VELKOR CAT#	TRADE SIZE	MIN	MAX	MIN	MAX
VK-HF/CT38	1/2"	12.30	12.80	17.50	18.00
VK-HF/CT12	3/4"	15.80	16.30	20.80	21.30
VK-HF/CT34	1"	20.70	21.20	26.20	26.70
VK-HF/CT114	1 1/4"	26.20	26.80	32.70	33.40
VK-HF/CT112	1 1/2"	34.80	35.40	41.40	48.30
VK-HF/CT2	2"	51.30	51.90	59.40	60.30

CUT SHEET (PDF)

Outside diameter tolerances: ±.005 in (.13 mm) for trade sizes 1/2–2" (16–53 mm); ±.010 in (.25 mm) for 2-1/2" (63 mm); ±.015 in (.38 mm) for 3" (78 mm); ±.020 in (.51 mm) for 3-1/2" and 4" (91–103 mm).

Specify the conduit construction, required size and matching connector together when requesting a quotation.
